ODS 460 Specifications

Features

• The 460 model Oil Disposal Shuttle (ODS) is compatible with F5, LOV3, LVE 200, LVG 200, EEE 14X, EEE 15X, EEE 18X, EEG 16X, EEG 24X, and EEG 25X model fryers.
• The 460 model Oil Disposal Shuttle (ODS) is not compatible with PFE 500, PFE 561, or PFG 600 (4 HD) model fryers.
• Filter pump and motor empties 50 lbs. (23 kg) of oil in less than a minute.
• Oil capacity is 50 lb (23 kg).

• Unit includes power cord and adapter:

• 115 V: NEMA L5-15P Plug

• 220-240V: NEMA L6-20P Plug

Dimensions

Uncrated Dimensions

	460
Width	15.88 in (403 mm)
Width of drain pan	12.17 in (309 mm)
Depth	38.50 in (978 mm)
Height	37.25 in (946 mm)
Height of drain pan	8.00 in (203 mm)

Crated Dimensions

	460
Volume	7.3 ft³ (0.20 m³)
